Model: DT0940
Load power: 12V-5A, 24V-3A
Input: DC5~24V. (Input = Output)
Size:9 (W)*40 (L) * 5~11(H) mm
Function:
- It typically works inside an aluminum channel protected by plastic cover, touch on the spring or LED dot on the plastic cover to control ON/OFF / CCT / Brightness. It works in Dual color mode and mono color mode:
Dual color Mode:
Short touch: the brightness will switch between: 0%(OFF) -20%-50%-100%
long touch: switch the color mixing between: 0%-20%-50%-70%-100%
Mono color Mode:
Short touch: the LED swich between ON/OFF with all softstart mode.
long touch: steplessly dim the brightness of LED from 0%-100%-0%alternatively. Brightness will be locked when finger move away. - The LED will automatically turn ON when sensor connect to power. Any New brightness or color temperature will be stored after touch
been released(offline memory)
