10mm Dual White led COB strip DC12V/24v

Product Description

• Specifications:

	PCB Width	PCB Type	DC Input	Cutting Unit(L)
	10mm	double layer,2OZ	12/24V	13.15/26.31mm



DC12V/24V
Order No.	CRI	Lumen Efficiency	Lumen/m	Power
SF608-COB0D	>90	75-105LM/W	820-1150LM	11+11W/m



Quality:

LED Chip: Default use high performance Chip with golden Wire and big inner chip size.

          FPC:  default use double layer(both side high quality white film coated), cooper 25+35um.  optional in 35+70um. and 35+105um.

          SMT Technology:  Pb Free

          Tape:   3M original/blue heating conductive tape

           Warranty:  3-year

Color:    Request for Spectrum Test Report

                   CRI>90

• •
    Default:  each 5meters packed into one roll, each roll packed into a PE bag. every 50bags put into a carton box.Packing

packing pictures:

• •  Customize

Free to design new Product (Flex strips, sensors, LED bars, LED aluminum Profiles)

Free to make Customized Packing, Labels, Logo Printing (on PCB, Lables, Packings)

Production Ability: 200 000 Meters / Month
